Fractal Design Meshify 3 XL Black TG Light Tint Gaming Case (FD-C-MES3X-02)

Key Features

Advanced airflow

Access performance engineering in a spacious format, with ample ventilation and an air guide which helps keep components running cool.

Evolved design

Elevate your space with an aerodynamic design aesthetic featuring a sleek, rockface-inspired mesh front panel.

Designed for gaming

Create a powerful gaming system with space for graphics cards up to 512 mm in length and E-ATX (330 mm) motherboard compatibility.

Easily accessible

Enjoy a smooth build experience with easily removable panels, including a sliding top panel featuring a fabric tab.

Powerful fans included

Includes three high-performance Momentum 14 fans, featuring LCP blades and true FDB bearings for improved cooling and quieter operation.

Ideal for custom loops

Create a build with advanced cooling, with space for up to a 420 mm top radiator and up to 360 mm front and side radiators.

Accessible I/O

Connect your devices easily with a top I/O featuring a 20 Gbps USB Type-C port, two USB-A ports and a combined audio jack.

Clean finish

Achieve a neat and tidy look with a clean interior layout featuring a cable cover and new cable aligners for easy routing.

Specification

3.5"/2.5" drive mounts : 2/4

Dedicated 2.5" drive mounts : 1

5.25” drive mounts : -

Expansion slots : 7

Front interface : 1 x USB Type-C 20 Gbps, 2 x USB Type-A 5 Gbps, 1x Audio Combo Jack, Power button

Total fan mounts : 10 (140 mm) / 7 (120 mm)

Front fan : 3x 120/140 mm, 2x 180 mm (3 x 140 mm Momentum Included)

Top fan : 3x 120/140 mm

Rear fan : 1x 120/140 mm

Bottom fan : -

Side fan : 3x 140 mm (no 120 support without radiator)

Dust filters : PSU (Bottom)

Cable routing space : 37.5 mm

Cable cover : Yes

Cable organizers : 3 Hook-and-loop straps + 3 Cable Aligners

Tool-less push-to-lock : Both Side Panels, Bottom Filter, Front Panel, Top Panel

Captive thumbscrews : Top Radiator Bracket, Air Guide, PSU Bracket

Left side panel : Tempered Glass

Right side panel : Industrial steel

Compatibility

Power supply type : ATX

Motherboard compatibility : E-ATX (330 mm) / ATX / mATX / ITX / EE-ATX / SSI-EEB / SSI-CEB

PSU max length : 230 mm

GPU max length : 512 mm

GPU max height : 189 mm (7 slot) including cables

CPU cooler max height : 182 mm

Front radiator : 280/360 mm

Top radiator : 360/420 (up to 475) mm

Rear radiator : Up to 120/140 mm

Side radiator : 360 mm (with brackets)

Dimensions

Case dimensions (LxWxH) : 575 x 245 x 515 mm

Case dimensions w/o feet/protrusions/screws : 565 x 245x 515

Package dimensions : 596 x 350 x 550 mm
